Description
All Frontier models feature Hawke's H7 optics, offering stunning high definition viewing with incredible color control and phase correction.
High performance lens coatings and Dielectric Coated prisms ensure the highest level of light transmission.
FEATURES:
- Dielectric Coatings
- High resolution phase corrected BAK-4 roof prisms
- Water repellent lens coatings
- Magnesium alloy chassis
- Focus from 2.5m
- Replaceable twist-up eye cups with position stops
- Stay-on lens covers
Nitrogen purged. Waterproof. Fog proof.
Hawke No-Fault Lifetime Warranty.
SPECS:
-
Magnification: 8x
-
Objective Lens: 32mm
-
Lens Coating: Wide Band, Anti-reflection, Fully Multi-Coated Lenses with Water Repellent Coating
-
Color: Green
-
Optical System: System H7
-
Field of View (°): 7.7
-
Eye Relief: 0.6" (16mm)
-
Exit Pupil: 0.16″ (4mm)
-
Field of View: 405ft @1000yds(135m @1000m)
-
Apparent Field of View (°): 62
-
Interpupillary Distance: 2.2 - 2.9″ (56 - 74mm)
-
Close Focus: 8.2ft (2.5m)
-
Prism Type: Roof
-
Prism Glass: BAK 4
-
Eye Cups: Twist-Up (Replaceable)
-
Eyecup ⌀: 1.7in (42mm)
-
Diopter Type: Right Eye
-
Tripod Mounting Thread: Yes (¼" - 20 UNC)
-
Height: 4.7″ (120mm)
-
Width: 3.9 - 4.6″ (100 - 118mm)
-
Weight:19oz (540g)
