Description
Life time no fault warranty!
FFP MOA Pro Ext. Reticle (30x)
The FFP MOA Pro Ext. reticle was developed specifically for first focal plane optical systems and based around the common principles of MOA spaced reticles. With MOA spaced markings extending out to 60 MOA of holdover, the FFP MOA Pro Ext. is a versatile reticle that provides aim points no matter how extreme the distance. All reticle measurements are MOA spaced and offer 1 MOA and 0.5 MOA brackets for range finding. Every fourth MOA spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
Scope Tube: 34mm
Magnification: 5 - 30x
Objective Lens: 56mm
Reticle: FFP MOA Pro Ext. (30x)
Illumination: 11 Levels (Red)
Illumination Control: Stepped Rheostat with Off Positions In-between
Parallax: Side Focus
Focal Plane: FFP (First Focal Plane)
Lens Coating: Fully Multi-Coated - 21 Layers
Optical System: System H7
Field of View: 22.5 - 3.8ft @100yds7.5 - 1.3m @100m
Field of View (°): 4.3 - 0.7
Eye Relief: 4in102mm
PX/Focus: 15yds - ∞14m - ∞
Click Value: 1⁄ 4MOA
Exit Pupil: 0.44 - 0.07″11.2 - 1.9mm
Turret Type (Elevation): Zero Lock 'n' Stop, Exposed, Locking, Resettable
Elevation Turret Clicks (max): 99 MOA
Turret Type (Windage): Exposed, Locking, Resettable
Windage Turret Clicks (max): 53 MOA
Ocular Type: Locking Fast Focus
Power Selector: Knurled Posi-Grip with Removable Zoom Lever
Length: 15.4in392mm
Weight: 29.3oz830g
